CX-One is an aluminium frame for building a fast, agile bike with true cyclocross DNA. Its sporty geometry is derived from the top-end CX-One Carbon, delivering quick response, precise handling and confidence through tight corners - exactly what you need when every second counts on a CX course.
The aluminium construction combines durability with low weight, while its balance of stiffness and compliance helps absorb impacts and smooth out rough terrain, improving riding comfort. Aluminium also offers good corrosion resistance, contributing to the frame’s long service life. A 12x142 mm rear thru-axle improves rear-end stability and handling precision, while the Flat Mount disc brake standard completes a clean, modern and race-ready setup. Tested at full speed, CX-One lets you take a more aggressive riding position for greater control and efficient power transfer when accelerating. But CX-One goes beyond the course tape. Clearance for tires up to 700x40C gives you plenty of freedom when building your setup - choose a race-focused CX configuration or fit wider tires and head out onto gravel. One frame, plenty of ways to ride.
The frame is available separately or as a complete frameset with an aluminium fork, headset and thru-axles. The frame-only version comes with the rear thru-axle and does not include a headset. Choose from three colorways: graphite, claret and silver-black.
Key features
- Aluminium construction with sporty geometry derived from the CX-One Carbon
- Fast, agile and precise handling
- 12x142 mm rear thru-axle
- Flat Mount disc brake mount
- Tire clearance up to 700x40C
- Available separately or as a complete CX-One frameset
- Three nice colourway options
SPECIFICATIONS
Seatpost: 31.6 mm
Front derailleur: 34.9 mm
Headset: integrated (IS42/IS52 mm)
Bottom bracket shell width: 68 mm
Bottom bracket standard: BSA
Thru axle: 12x142 mm rear
Brake mount: Flat Mount
Max. tire size: 700x40C
Frame weight: 1850 g (frame 1750 g + thru-axle 40 g)
Colors: graphite, claret, silver-black (raw aluminium with a protective clear coat and black decals)
Sizes: XS, S, M, L, XL
